NVIDIA's Blackwell architecture (B200/GB200) addresses the core GPU memory bottleneck for AI workloads through several key advances: a dual-die design with 192 GB HBM3e at 8 TB/s bandwidth (2.4× over Hopper), a 126 MB L2 cache (2.5× increase), and unified CPU-GPU memory via NVLink C2C at ~900 GB/s. The GB200 Superchip pairs two Blackwell GPUs with a Grace ARM CPU and ~480 GB LPDDR5X, providing roughly 10× the usable memory of a single H100. This means models like Llama 3 70B that previously required multi-GPU setups with tensor parallelism now fit on a single superchip, simplifying deployment and eliminating inter-GPU communication overhead. The article covers the full memory hierarchy from registers through L1/L2 cache, HBM3e, and LPDDR5X, explaining how each tier serves AI inference workloads.
