The Cheetah MX4 Mini is an open-source 3D printer motherboard measuring 80x90mm, built around the STM32H743VIT6 MCU. It features 4 TMC stepstick drivers with UART/SPI support, 3 thermistor inputs, LCD/TFT display support, BLTouch probe compatibility, and dual heater outputs. The 4-layer PCB design includes dedicated power/ground planes, supports 12/24V input at 15A, and works with Marlin and Klipper firmware. JLCPCB assembly costs approximately $150 for 5 boards, with individual component costs around $20 plus shipping.
