<p><a href="https://mermaid.js.org/" target="_blank" rel="noopener nofollow">Mermaid.js</a> is a powerful tool to visualize flows, architectures, and data — directly from plain text. But did you know you can animate arrows and apply custom styles to make your diagrams easier to read and much better looking?</p>
<p>Here’s how to do it:</p>
<hr>
<h2>🎯 1. Animate Arrows to Show Flow</h2>
<p>You can animate arrows in Mermaid by giving them an ID and using the animation syntax.</p>
<pre><code class="language-mermaid">flowchart TD
  A[&quot;Client&quot;] r1@--&gt;|Request| B[&quot;Ingress&quot;]
  r1@{ animate: true, animation: slow }
</code></pre>
<h3>✨ Result:</h3>
<ul>
<li>The arrow from Client to Ingress will animate slowly.</li>
<li>Use animation: fast if you want quicker motion.</li>
</ul>
<hr>
<h2>🎨 2. Style Your Nodes with Color</h2>
<p>Plain nodes work, but styled nodes make diagrams easier to scan at a glance. Here’s how:</p>
<pre><code class="language-mermaid">flowchart TD
  A[&quot;Client&quot;]
  B[&quot;Service&quot;]
  C[&quot;Pod&quot;]

  A --&gt; B --&gt; C

  style A fill:#fcd34d,stroke:none
  style B fill:#bfdbfe,stroke:none
  style C fill:#bbf7d0,stroke:none
</code></pre>
<h3>💡 Tips:</h3>
<ul>
<li><code>fill: sets</code> background color.</li>
<li><code>stroke:none</code> removes borders.</li>
<li>Use soft/pastel colors (<code>Tailwind palette</code> is a good <a href="https://uicolors.app/" target="_blank" rel="noopener nofollow">reference</a>).</li>
</ul>
<hr>
<h2>🧩 3. Combine It All: Animations + Styles</h2>
<p><img src="https://media.daily.dev/image/upload/s--Fs9x6TU4--/f_auto/v1744303792/ugc/content_76c80383-1cdb-4a6d-8033-3d4ab4abdc94" alt="example-animation"></p>
