Taalas, a startup, has built a fixed-function ASIC chip with Llama 3.1 8B weights physically etched into silicon transistors, achieving 17,000 tokens/second inference — roughly 10x faster, cheaper, and more energy-efficient than GPU-based systems. By hardwiring the model's 32 layers sequentially on-chip, data flows directly through physical transistors without the constant VRAM fetch cycles that create the memory bandwidth bottleneck on GPUs. The chip uses on-chip SRAM only for KV cache and LoRA adapters, avoiding external DRAM entirely. A novel single-transistor 4-bit multiply scheme enables the dense weight storage. The base chip uses a generic logic gate grid, requiring only two mask customizations per model, allowing a new model variant to be taped out in roughly two months.

How Taalas "prints" LLM onto a chip?

HOW NVIDIA GPUs process stuff? (Inefficiency 101)

But isn't fabricating a custom chip for every model super expensive?
