DeepSeek's engram introduces a new way to retrieve knowledge through scalable lookups. This boosts LLMs across all tasks (including reasoning tasks) by freeing up attention and MoE layers from the need to reconstruct facts in static patterns.

In this video, let's explore how and why Engram works.

00:00 Attention
01:56 How facts are stored in LLM (FFN/MoE)
06:27 Retrieving knowledge via lookup
07:32 Hashing
10:47 Multi-head hashing
11:56 Context-aware gating
16:06 Multi-branch architecture (mHC)
16:53 Integrating Engram into a Transformer
18:01 Sparsity allocation (Engram vs MoE)
20:16 Performance on benchmark tasks
22:08 Why does Engram improve LLM reasoning?
23:45 Where should we place the Engram?
25:41 Does the Engram model really make the model deeper?
27:05 Embedding scaling and the future of LLMs

References:
- [Engram] https://arxiv.org/abs/2601.07372
- [Layer Embeddings] https://developers.googleblog.com/en/gemma-explained-embeddinggemma-architecture-and-recipe/
- [DeepEmbed] https://www.rwkv.com/
- [SuperBPE] https://arxiv.org/abs/2503.13423
- [SCONE] https://arxiv.org/abs/2502.01637
- [OverEncoding] https://arxiv.org/abs/2501.16975
- [Byte Latent Transformer] https://arxiv.org/abs/2412.09871
- [LongCat-Flash-Lite] https://arxiv.org/abs/2601.21204
- [Large Lookup Layers] https://arxiv.org/abs/2601.21461

Video made with manim: https://www.manim.community/

Note: I caught a cold while making this video 🤒, so the part of the voiceover is generated by my cloned voice. Sorry if the voiceover felt a bit unnatural.

Jia-Bin Huang

DeepSeek's Engram module introduces a hash-based explicit memory lookup mechanism for transformers, distinct from RAG. Instead of computing factual knowledge through dense matrix multiplications, Engram uses a multiplicative XOR hash to index into large embedding tables, enabling direct fact retrieval for token n-grams. Multi-head hashing mitigates collisions across 8 independent tables. A context-aware gating mechanism (using query-key dot products with sigmoid activation) filters irrelevant lookups, and a short depthwise causal convolution widens the receptive field. Placed at transformer layer 2, Engram injects factual context before attention begins, freeing subsequent layers for reasoning. Experiments show the optimal parameter split is ~75-80% MoE and 20-25% Engram. Embedding tables can reside in CPU RAM and be prefetched before computation, avoiding GPU memory overhead. Ablations confirm factual tasks collapse to 29-44% performance when Engram is disabled, while reasoning tasks remain largely intact.

DeepSeek Gave LLMs a Real Memory (It's Not RAG)
